Ajax Alarm Control Hub BP
Save
100%
100%
Hub BP Jeweller is an innovative security control panel designed to secure properties without a constant power supply. It's ideal for protecting vacant houses, construction sites, and temporarily unused offices. Unlike other control panels, Hub BP is powered by internal and external batteries, ensuring long-term autonomous operation. Hub supports event photo verification and features dual SIM connectivity, guaranteeing reliable communication. Thanks to its battery power saver feature, the device optimizes battery usage, providing continuous protection for extended periods.
- Connect up to 100 devices to the hub
- Up to 50 users per hub
- Supports the MotionCam
- Connects using 2 Micro-SIM's
- Checks in with devices every 36 seconds (other systems tend to check in every 20 minutes)
- Compatible with iOS and Android
| Technical Specifications | |
| Classification | Wireless battery-powered control panel with in-built channels for external communication and support of detectors with photo cameras |
| Maximum number of devices connected to the hub | 100 |
| Maximum number of cameras/DVRs connected to the hub | 25 |
| Maximum number of users | 50 |
| Maximum number of rooms | 50 |
| Maximum number of groups | 9 |
| Number of REX connected | 5 |
| Scenarios supported | 32 |
| Mobile apps | iOS 9.1 and later Android 4.1 and later |
| Communication channels | 2G (GSM900/DCS1800 (B3/B8)) 3G (WCDMA 850/900/2100 (B1/B5/B8)) LTE (FDD B1/B3/B5/B7/B8/B20) |
| Alarm signal | Delivery time: 0.15 s Types of notifications: SMS message, call, push-notification |
| Communication with Central Monitoring Station | Support protocols: SIA DC-09 (SIA-DCS), SurGard (Contact ID), ADEMCO 685, Other proprietary protocols |
| Power supply | External: 4.2–16 V⎓, up to 2A (zinc-air battery or external power source) Internal: 4.2–16 V⎓, up to 2A (rechargeable lead-acid and LiFePO4 batteries [not included] or non-rechargeable LTC batteries [not included]) Device operating DC voltage range: 3.5–16 V⎓ |
| Autonomous operation | On external battery in full function mode
up to 18 months On a 12 V⎓, 600 Ah, zinc-air non-rechargeable external battery (not included) On external battery in Battery saving mode On a 12 V⎓, 600 Ah, zinc-air non-rechargeable external battery (not included) On internal battery in a Battery saving mode On a 7.2 V⎓, 95 Ah, LTC non-rechargeable Internal battery NB (7.2V/95Ah) (not included) up to 4 months On a 6.4 V⎓, 27 Ah, LiFePO4 rechargeable Internal battery RB (6.4V/27Ah) (not included) up to 2 months On a 12 V⎓, 7 Ah, lead-acid rechargeable internal battery (not included) |
| SIM card support | 2 x Micro-SIM 2G/3G/4G |
| Operating temperature range | -10°С to +40°С |
| Anti-sabotage | Protection against fraud Jamming detection Tamper-resistant |
| Jeweller Radio Technology | Communication range with detectors — up to 2,000 m in an open space Two-way communication between devices Operating frequencies — 868,0−868,6 MHz Self-adjusting RF output power — up to 25 mW Block encryption based on AES algorithm Detector polling period — 12−300 s Frequency hopping |
| Dimensions | 196mm x 238mm x 100mm |
| Weight | 1,010g |
| Certifications | Grade 2 (EN 50131), PD6662:2017, CE, IP40 |
