DoorProtect Detector (Fibra)
Save
100%
100%
Wired opening detector that notifies of first signs of room intrusion by means of a broken door or window. It can be mounted on all types of doors including a metal base. The device detects the door or window being opened by means of British-made high-end reed switches on which the magnetic field acts. It can operate in transmitter mode, sending a signal from the 3rd-party wired sensor to the hub.
- Bus connection with 4-core cable, up to 2000 meters (when using twisted pair U/UTP CAT5)
- Reed switch sensing element
- Alarm signal delivery time of 0.15 s
- Magnet can be installed to the right or left side of the detector
- Connection for additional detector
| Technical Specifications | |
| Classification | Point magnetic and contact security detector |
| Installation method | Indoors |
| Compatibility | Operates with Hub Hybrid (2G) and Hub Hybrid (4G) only |
| Sensing element | 2x Reed switch |
| Alarm signal delivery time | 0.15s |
| Activation threshold | Small magnet: 1 cm Big magnet: 2 cm |
| Opening sensors actuation | Up to 2,000,000 (for each reed switch) |
| Additional detector connection | Wired detector with the normally closed (NC) contact type |
| Fibra technology | Recommended cable type for detector connection: Signal cable (4 x 0.22 copper) / Twisted pair U/UTP CAT5 (4 x 2 x 0.51) Connection wire length: Up to 2000m Device polling period: 12−300 s |
| Power supply | Power supply voltage: 24V Power consumption: up to 45 μA |
| Permissible humidity | Up to 75% |
| Operating temperature range | -10°С to +40°С |
| Anti-sabotage | Protection against fraud Tamper-resistant |
| Dimensions | 90.5mm х 21mm x 18.5mm |
| Weight | 54g |
| Certification | EN 50131 (Grade 2), PD 6662:2017, IP50 |
