12/24V Power Supply - 7.2A/3.6A, 99W (DIN mount)

Call us for a price

*Lead time of 2-3 days*

Order Code: CPAC-909022008

Description

High quality power supply that can switch between 12V and 24V DC outputs, and comes in a DIN rail mountable form. Battery charger leads are supplied as standard to easily connect a battery back-up capability. For battery back-up the following batteries are needed in addition:

- One 7Ah 12V DC battery is required for a 12V DC PSU
- Two 7Ah 12V DC batteries connected in series are needed for a 24V DC PSU

Technical Specifications
Power Input	100-230V AC
Power Output	13.8V @ 7A / 27.6V @ 3.5 A
Frequency	50/60Hz
Weight	616g
Standards Compliance	UKCA, CE, UL, FCC, IC, RoHS & WEEE compliant
Operating temperature range	-20°С to +50°С
Dimensions	176mm x 90mm x 45mm
