Architect Bluetooth RFID HF Reader (Standard)
Save
100%
100%
The Architect A Blue is a standard RFID/Bluetooth/NFC reader designed to be Vandal-proof and extremely secure, the Architect A Blue Reader is specially designed for all of your high security access control applications coupled with industry leading Mobile ID support for user friendly deployments.
- Accelerometer-based Tamper Detection System
- High Frequency (13.56MHz), Bluetooth and NFC
- Audible Sounder and RGB LEDs
- IP65 rated
| Technical Specifications | |
| Programmable Output Formats | PAC, PAC64 |
| Supported ID Device formats | PAC OPS™ Lite (Cards and Tokens) PAC OPS™(Cards and Tokens) |
| Maximum Read Range | Up to 80mm for HF Up to 20m for Mobile IDs (configurable) |
| Protection Rating | IK10 |
| Ingress Protection Rating | IP65 |
| Audio Visual Indication | Audible Sounder and 2 x RGB LEDs (360 configurable colours) |
| Tamper Output | Accelerometer-based tamper detection system with key deletion option |
| Recommended Cabling | 6 core 24 AWG alarm cable unscreened for PAC |
| Operating Voltage | 7V to 28V DC |
| Maximum Current Requirements | <150mA @ 12V DC |
| Weight | 250g |
| Standards Compliance | CE, UL, FCC, IL |
| Operating temperature range | -30°С to +70°С |
| Permissible humidity | 0% to 95% |
| Dimensions | 107mm х 80mm x 26mm |
