UR Fog Battery Powered Fogging System (BAT 300)
Save
100%
100%
The first innovative and unique battery fogging system with the highest level of security and ZERO energy consumption. The BAT 300 from UR Fog can work fully autonomously for 6 months without power, making it the ideal solution for vans, trucks, boats, caravans and more, where a regular external power supply may not be possible. Compared with a smoke generator, this fogging system leaves no residuals or bad smells, and can be used with food-grade fluid for use in restaurants, cafes and kitchens.
- Up to 8 shots per cartridge
- Up to 60 seconds of shooting time
- Up to 100m³ of coverage
- Fluid and batteries not included
- 2x Ajax relays pre-installed
| Technical Specifications | |
| Inputs | 3 wired inputs: Arming, Shooting and PIR / Panic |
| Outputs | 3 wired outputs (max 16 V – 50 mA): empty fluid, fault, low battery |
| Serial ports | 2 serial interfaces RS232 with UR FOG Standard protocol for expansions |
| Microswitch tamper for cover | Optional |
| External signaling LEDs | Red (Fault) Green (Ready) Blue (Armed) |
| LAN/WiFi board | Optional |
| Registration on Active Cloud | Yes |
| Multi-hole and directional nozzles | No |
| Nozzle extension | No |
| Number of shots with one cartridge | 25 m3 (8 shots), 50 m3 (4 shots), 100 m3 (2 shots) + 1 extra test shot |
| Shot times (seconds) | 2 (test shot), 15 sec. (25 m3), 30 sec. (50 m3), 60 sec. (100 m3) |
| Fluid cartridge capacity | 125ml |
| Disposable non-pressurized cartridge | Yes |
| Operating temperature range | -10°С to +50°С |
| Colour | RAL 9010 |
| Dimensions | 200mm х 150mm x 300mm |
| Weight | Without batteries: 1.9kg With batteries: 7.6kg |
